Relé De Sobrecarga Eletronico E16Du 18.9A E16DU-18.9 1SAX111001R1105 ABB

Código: 1SAX111001R1105 Marca: ABB

Para mais informações entre em contato conosco através do telefone (11) 5091-2400 ou através do Fale Conosco

Qtde: Incluir no Orçamento Estoque: Disponível

Tipo de produto alargado:

E16DU-18.9
ID do produto:

1SAX111001R1105
EAN:

4013614395260
Descrição do catálogo:

E16DU-18.9 Electronic Overload Relay 5.7 ... 18.9 A
Descrição longa:

The E16DU-18.9 is an self-supplied electronic overload relay, which means no extra external supply is needed. It offers reliable and fast protection for motors in the event of overload or phase failure. Easy to use like a thermal overload relay and compatible with standard motor applications, the electronic overload relay is convincing, above all, due to its wide setting range, high accuracy, high operational temperature range and the possibility to select a trip class (10E, 20E, 30E). Further features are the temperature compensation, trip contact (NC), signal contact (NO), automatic- or manual reset selectable, trip-free mechanism, STOP- and Test function and a trip indication. The overload relays are connected directly to the contactors. Single mounting kits are available as accessory.
