Módulo De Contagem - 2 Entradas Digitais - 100 Khz - 24 Vdc - Terminal Mola TM5SE2IC01024 SCHNEIDER

Código: TM5SE2IC01024 Marca: Schneider

Para mais informações entre em contato conosco através do telefone (11) 5091-2400 ou através do Fale Conosco

Qtde: Incluir no Orçamento Estoque: Disponível

This product is part of the Modicon TM5 range, an offer of modules for IP20 modular I/O system. The counter module provides 2 inputs, 16/32bit counter resolution with sink (positive) discrete logic. It is a counter module with a discrete input voltage of 24V DC, a maximum power dissipation of 1.51W, an input/output current consumption of 63mA at 24V DC, an auxiliary input of 2 x 24V DC and an encoder power supply of 24V DC. This product is part of a flexible and scalable I/O configuration for automation solutions. The maximum cycle time is 2ms and counter inputs resolution is 16bit/32bit. It is an IP20 rated product. It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by CE, C-Tick, CSA, GOST-R and CULus. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Modicon LMC058 motion controller and Modicon M258 logic controller. This IP20 modular IO system provides a flexible and scalable configuration of expansions/distributed I/O islands by connection with Modicon controllers (TM5 bus) or via CANopen bus/Sercos bus for Modicon and PacDrive 3 controllers as well. Flexible and scalable, designed for complex machines.
