Disjuntor Motor Tripolar 690V In=0 16A Fixo Ics=100Ka (690Vca) Modelo Mo132 0.16 Somente Proteção Magnética MO132-0,16 1SAM360000R1001 ABB

Código: 1SAM360000R1001 Marca: ABB

Para mais informações entre em contato conosco através do telefone (11) 5091-2400 ou através do Fale Conosco

Qtde: Incluir no Orçamento Estoque: Disponível

Tipo de produto alargado:

MO132-0.16
ID do produto:

1SAM360000R1001
EAN:

4013614400162
Descrição do catálogo:

MO132-0.16 Manual Motor Starter Magnetic Only 0.16 A
Descrição longa:

The MO132-0.16 manual motor starter magnetic only is a compact 45 mm width device with a rated operational current of Ie = 0.16 A. This device is used to manually switch on and off loads/motors and to protect them reliably and without the need for a fuse from short-circuits. The manual motor starter offers a rated service short-circuit breaking capacity Ics = 100 kA at 400 V AC. A combination together with overload relays or motor controllers allows the protection of motors. Further features are the built-in disconnect function, trip-free mechanism and a rotary handle with a clear switch position indication. The manual motor starter magnetic only is suitable for three- and single-phase applications. The handle is lockable to protect against unauthorized changes. Auxiliary contacts, signalling contacts, undervoltage releases, shunt trips, 3-phase bus bars, power in-feed blocks are available as accessory.
